hi guys https://cdn.modulargrid.net/img/racks/modulargrid_3001795.jpg
i managed to get a working system plus i fitted a midi to cd adapter at the end
problem is the two peices of hardware ive bough which are :
behringer swing ....this is a nightmare and i sold on just before bonfire night
rd-6 bu : nice but again connection problems
so my question is where to i connect the cables ( using midi ) and were do
any other cables go that are required
my previous post was a great help
Did you want to sync the sequencer with midi in?
You'll need a midi in that supports it and the v/oct and trigger from midi.
Do you need two note and trigger outs from midi, or just one set?
Do you need this box to be able to send midi out too?
This arrangement could make things easier.
Input and signal generation on the left. A multiple between to share those signals. Voices to your output on the right.
I moved the power supply to be better out of the way of patch cables.
The 110 needs those two envelopes, so I kept it nearby.
The 2600 vco doesn't have a vca, but you could put it into the 110's 2nd vcf input.
The 121 filter at the end lets you tame and shape your final output, but also gets you a 3 x 2 mixer to combine your audio generators,
or blend the 2600 vco's vaveforms.
I kept the CU1A output, but it's kind of terrible.
You have to power it from the USB-C input, it's not hooked to the power supply.
So with no usb input power, there's no output audio and no headphones.
Just a dumb design. Nothing but trouble.
(and the 921A Oscillator Driver isn't applicable here)
I added the 903A random because there was a 4hp hole,
and it's cheap, and you don't have any random noise fun.
If you want the sequencer to track midi in, you'll need an interface that supports midi clock/sync out.
There's loys of them available.
