Maffez

This is DIY stuff only. Find gerber files and schemos here: https://maffez.com/?page_id=2748

Model Y, Model F, MS-1 Expander, Model 5 and Model P (Modded) are among Maffezs most popular products.

Contact

A cozy place between blankets and soldering gear (but don‘t solder in bed, seriously, this would be dangerous).

News from the Labs

Maffez

10. Jun 2025, 20:34 Maffez

Super cool that my modules are now in a manufacturer register even though you manufacture them yourselves. Lie, put your own name here :) Btw model p is my latest, a 8stage SSI2140 based phaser: https://maffez.com/?page_id=5073

Modules

MS-1 Expander

Passive breakout module for the MS-101/1 synthesizer

$15 MSRP

8 HPExternal Utility

Model F

AS3109 based Multimode Filter

$30 MSRP

8 HPFilter

Model A (AS662D dual VCA)

Model A (AS662D dual VCA)

Dual VCA built around the AS662D chip

$33 MSRP

8 HPVCA

Model A+

Dual As662-based VCA with extras

$47 MSRP

16 HPAttenuator Dual/Stereo Dynamics Mixer Panning PreAmp Utility VCA

D3MIX

Triple levelling, mixing, multing tool

$46 MSRP

8 HPAttenuator Mixer Multiple Switch

Model Y

Maffez

8 HPDrum Oscillator

Model P

2x 4Stage Phaser

8 HPEffect Filter Phase Shifter

Model P (Modded)

Model P (Modded)

2x 4Stage Phaser

8 HPEffect Filter Phase Shifter

Model 5

SH5 inspired VCF

8 HPFilter

POLEY

Pole Mixing VCF

$94 MSRP

8 HPFilter

Model A2 (AS662D dual VCA)

Model A2 (AS662D dual VCA)

Yep, this is an updated version of the simple Model A VCA...

8 HPDynamics VCA
