Multiple dual channel RY

Passive multiple dual channels with led indicator

Passive multiple dual channels (switched multiple) with LED indication of the selected channel : blue=channel A, green=channel B. Led off, the signal is muted.
NEW: at the back of the module, jumpers allow the module to be divided into two independent parts (2x4). You can even go further, for example you can split channel A into two parts (2x4) and leave channel B in one part (8 I / O). I let you imagine the many possibilities of this option :)

Customization option (+2€): If you wish, I can replace some switches (latching by default) by momentary (If you do not move the lever to the right or left, it returns to its central position. This creates effects or momentary actions!) on request, at your convenience depending on your use ;-)

• 8 jack's IN/OUT
• 2 channel's (A&B) & a central position "off"
• Two parts option with jumper
• Bicolore LED's
• Independent LED circuit to avoid signal disturbance or voltage drop
• Latching switch's
• Skiff friendly
• Black or white panel
• Choice to bicolore LED (blue/green or blue/red or red/green or red/yellow or white/red or blue/yellow)

Manual: http://ph.neutre.free.fr/Telechargements/Manual%20ph%20Multiple.pdf

More bicolore LED's available:

The price includes: module, screw M3 and connection cable. Excluding shipping costs !!

Manufactured by Christian from ph modular.
Available as an assembled Module, no kit.
Tested and assembled by hand. All components are through, so all "ph" modules are repairable. Built to last ;-)

Also available in white panel :

To order, please contact me (phneutre56@gmail.com) the terms of payment, delivery times and shipping costs, will be detailed by return mail.
The payment will be in euros (€) and can be done by paypal. Delivery possible in the world, please contact me (phneutre56@gmail.com)
Shipping costs :
