16 HP
40 mm deep
Current Draw
? mA +12V
? mA -12V
50 mA 5V
$260 Price in €

This Module is currently available.


Parametric Equations Based MIDI Sequencer

Parametric Equations Based MIDI Sequencer

Dimensions uses parametric equations to generate MIDI patterns.

Open source, ESP32 MCU based (DOIT Esp32 DevKit v1)
Upload your own paramteric equations (through the Arduino IDE)
Monophonic sequencer
Eurorack format (3U/16HP = approx. H129mm x W81mm)
Uses 5V feed from Eurorack bus bar
Runs off USB power also
1.5inch OLED (128x128 pixels)
MIDI only (no CV!)
TRS Type B MIDI 3.5mm Jacks

Available front panel designs: Black/White or Psychedelic**


3U/16HP = approx. H129mm x W81mm
Depth approx. 40mm
+12V = 0mA, -12V = 0mA, +5V = 50mA
Runs off USB power also

submitted Mar 3rd 2022, 01:21 by femifleming
