Dimensions
4 HP
13 mm deep
Current Draw
2 mA +12V
2 mA -12V
0 mA 5V
Price
$82 Price in €

No info about availability.

Specs are approved by the manufacturer

A fast and versatile S&H module

The sample & hold module is a precise circuit which offers very short sample acquisition time of about 10μs with DC gain accuracy of 0.01%. Droop rate is less than 5mV/min, which gives you very long hold times.
The extremely high input impedance of 10 GOhms allows it to capture signals from high impedance sources without degrading accuracy.
High input voltage range of 20Vpp allows you to capture every signal in your modular system.
The circuit offers excellent values on a small footprint.

All I/O signals are available via pinheader on the PCB fro internal prepatching.

Inputs:
IN
SAMPLE

Outputs:
OUT

http://seismic.industries/sample-hold/


submitted Dec 1st 2015, 07:32 by seismic_industries | last Change Feb 24th 2016, 19:22 by seismic_industries
