Dimensions
8 HP
25 mm deep
Current Draw
50 mA +12V
50 mA -12V
0 mA 5V
Price
$110 Price in €

This Module is currently available.

Specs are approved by the manufacturer

Single ended Discrete 24dB Lowpass VCF & VCA

SED single ended discrete VCF and VCA plus 3 Channel Mixer
Powerful but sweet Lowpass Filter with 24 dB and shimmering highs.
Three Channel Mixer
Overdrive Button and Resonance Boost level
Discrete VCA with low noise and low distortion
Jumper at the back to switch from 5V, 7.5V and 10V CV input for VCA
Inputs:
A, B and C Audio IN
Keytrack IN(1V/Oct) for VCF Cutoff
ADSR IN for Cutoff
Linear FM IN for Cutoff
CV In for Resonance and CV IN for VCA.
Audio IN for VCA (normalized, no Input VCF goes to VCA, Input switched VCA is separately)
VCF Audio OUT
VCA Audio OUT
Power consumption: +/-80mA
Rackspace: 8HP
