Skis

smd version of Bastl Skis v1.

This is smd version of Bastl Skis v1.

Main differences are:

It has skis (two sliders) vs. no skis in Bastl version
6HP vs. 5HP, for obvious, OCD reasons
Range switch vs. range backside jumper (although this switch works as a jumper - instead of going from freq0 to freq1, and then from freq1 to freq2 in the second position, it goes from freq0 to freq1, and then from freq0 to freq2)
Version 2 of Bastl Skis has decay CV input, and this one doesn't have it
Version 1 of Bastl Skis was THT and had two sandwiched boards, and this one is SMT in one board.
Status: tested and working.

CC-BY-SA Václav Peloušek bastl-instruments.com

https://github.com/kraakenstuff/Skis
