Kingluci Logic+

Inverter, Sum/Div, AND, XOR

This module is a typical utility, a swiss army knife. It has two parts. Each consist of two channels (A&B or C&D). There is an inverter for every channel, a sum and differenc for A&B oder C&D and a Logic AND and XOR. Additionaly the channels A and C can be summed with a -5v signal (its this addition and the XOR that makes for the +Version) . This helps invert trigger signals around 0v.
