Haraldswerk Matrix Mixer

4x4 Matrix

This is a 4 x 4 matrix mixer with switches for unipolar/bipolar mode for each column. Unipolar means that the controls work as attenuators. Bipolar means that the controls work as attenuverters. In this mode the amplification is zero in the middle position of the corresponding potentiometer. Turning the knob counterclockwise from the center position the signal is subtracted from the output sum. Turning the knob clockwise from the center position the signal is added to the output sum. The module is DC-coupled and can be used for audio and control voltage mixing.

Specs and features
4x4 Matrix
Switchable unipolar or bipolar mode
Power consumption below 30mA each rail
