Dimensions
4 HP
46 mm deep
Current Draw
17 mA +12V
19 mA -12V
0 mA 5V
Price

Module is available as a DIY project only.

This Module is a prototype or in a concept phase.

Comparator (DIY)

Incoming signal compared with two variable offsets to produce two pulse outputs with variable mark/space ratio.
Also (unrelated, but hey it is my DIY module) an ultra-fine-tune pot for a Dixie 2 or 2+ (the grey knob)

https://github.com/svgeesus/ondesModulaire/tree/gh-pages/dual%20comparator


submitted Aug 18th 2013, 22:28 by Nantonos | last Change Mar 3rd 2018, 19:07 by Nantonos
