Coriolis Instruments 1U LPG

Other/unknown

Unlisted Low Pass Gate

Dimensions: 8 HP

Module is a 1U tile in Intellijel format

Current Draw: Module does not draw current

Price

Module is available as a DIY project only.

This Module is currently available.

MG ID: 42630

A simple passive low-pass gate with -6dB slope in a small 1U package.

This low-pass gate (LPG) module design was inspired by the Two Tone module from Ben Moren as well as Ken Stone's LPG. The original "Two Tone" LPG can be found here.. The filter is 2nd order RC filter (the LDRs in the vactrols being the R), so it has a filter slope of -6dB.

https://github.com/coriolisinstruments/EurorackModules/tree/master/1Utilities/1U_LPG

submitted Feb 6th 2023, 03:40 by djmjr
