Blinkenlights Microscope

A tiny oscilloscope with vectorscope mode Kit, to visualize your Eurorack patches

This kit contains everything you need to build a tiny oscilloscope / vectorscope: PCB, front panel, and all components.

8HP wide
25mm deep (skiff friendly)
1 channel auto triggered mode (will attempt to 'lock' the waveform within the screen)
2 channel mode, where channel A is auto triggered
1 and 2 channel scan modes (where waveform is not locked)
2 channel vectorscope mode (A and B channels control the X and Y coordinates of the display)
approximate frequency of channel A shown onscreen (toggle this info on/off with a push button)
Now with Thonkiconn Jacks - less soldering and tougher build quality

Vectorscope mode is one of the most powerful and interesting ways to use an oscilloscope, and can be used to measure the purity of sine waves, and determine whether 2 signals are in tune, amongst other things.

Please watch the video below, where I demonstrate this module's features far better than I could ever describe them in writing!

This scope is intended to show you a fun visualisation of the sounds you make with your modular. It's not accurate enough to give precise measurements on the lab bench.

https://www.tindie.com/products/nbirch/microscope-eurorack-oscilloscope-module-kit-8hp/
