OR Combiner
https://manhattananalog.com/products/mutinator
If you had an Unicorn Account you could see a chart with the price development of this module and the average price asked for this module.
Multi-channel switched trigger combiner.Allows you to mix/combine triggers from 8 sources and assign across 4 outputs.It's a really effective performance tool for percussion focussed systems, as you can mute and combine trigger sequences and assign across the 4 outputs on the fly.There are some small dings on the faceplate but nothing major. Functionally it is working 100%More detail from elsewhere on the internet:The Mutinator is a “human interface module” and can best be described as a multi-channel switched trigger combiner. It features 4 parallel channels, each with two switched inputs and a single output. Within each channel the inputs are combined using analog OR logic and sent to the output, whose activity is indicated by an LED. The operation of the switches is ON-OFF-(ON). In the ON position the corresponding input’s signal passes to the combiner. In the OFF setting, that input is muted. The (ON) setting is known as ‘momentary-on’ - in this position the signal will pass to the output, but the switch will return to the OFF position as soon as you release the switch lever. This allows you to more easily ‘play’ the switches in a performance situation. Unlike some other trigger-combiner designs, this module contains active circuitry. Incoming pulses are reduced in amplitude by the logic section but an output amplifier compensates for this. In addition, the level of the incoming pulses is limited to protect the module. This means you can run any positive-voltage trigger or gate source in your studio into the inputs without fear of causing damage to the module. This limiter also prevents the Mutinator from producing an output voltage above ~10.2v, which makes the outputs safe for any other modules in your Eurorack modular synthesizer.Please note that this module is designed to pass trigger and gate information only. It does not faithfully preserve the level of the input signal nor will it pass any voltage below 0v. It will not perform as expected with audio or bipolar control voltage signals.Specification:-depth: 32mmPanel size: 12HP
