Dimensions
4 HP
26 mm deep
Current Draw
44 mA +12V
10 mA -12V
0 mA 5V
Price
$188 Price in €

This Module is currently available.

Specs are approved by the manufacturer

Complex CV generator with step, LFO, and random modes.

Clep Diaz is a handy and small step CV and LFO generator. In step and random modes, use the encoder to control the number of steps in the sequence; in LFO mode, the encoder controls the amplitude of the wave. Toggle the directionality of the sequence: up, down, or up/down to customize the CVs further. CD also gives CV control over the number of steps in the sequence and an end-of-cycle trigger output. Unipolar and bipolar outputs allow maximal control.

Clep - from Latin clepsydra for "a clock used in timing orators"

Diaz - from Latin diazoma for "the space between"

"Timing the space between"

https://www.noiseengineering.us/shop/clep-diaz


Ø 4.64 (42 Votes) Average Rating
submitted Sep 10th 2018, 23:00 by noise-e | last Change Oct 1st, 00:19 by noise-e
