6 HP
40 mm deep
Current Draw
35 mA +12V
30 mA -12V
0 mA 5V
$151 Price in €

This Module is currently available.

Specs are approved by the manufacturer

Dual VCA with Linear and Exponential control

The Morphor Dual VCA is a compact and complete dual DC-coupled VCA module. This module will definitely come in handy as a general purpose VCA without taking up too much space. The two separate VCA sections each feature extensive gain control (main knob + attenuated CV jack), an indicator LED and a switch to select Linear or Exponential control. This way, the module can be used both for audio and CV processing. Without a cable plugged in, the first output gets normalised to the second, resulting in a 2-channel mixer output.

Other information:

Attenuation up to 120dB
Dimensions: 6HP width, 3U Eurorack standard
16-pin power socket



submitted Nov 23rd 2022, 14:27 by Morphor | last Change Dec 5th 2023, 09:32 by Morphor
