ZDROJ

ZDROJ - nocompromise back case Linear Power Supply.

ZDROJ circuit is completely analog with linear regulation, which causes minimal interference to the secondary side of power supply. Primary side contains an LC filter, which removes interference from 230V AC mains. Toroidal transformer with a metal cover is the key element to minimize electromagnetic interference. Metal cover shields electromagnetic field around the transformer. Many electronic parts are of SMD origin . ZDROJ is made on quality PCB with copper thickness of 70 μm, which ensures high reliability and minimal losses on PCB routes. Contains prewired IEC inlet with switch attached as an accessory for your maximum safety.

Designed, manufactured, and assembled by hand at Konstant Lab - Slovakia / EU.
http://konstantlab.audio/
https://www.facebook.com/konstantlab
https://www.instagram.com/konstantlab/

Technical parameters:

Power:
39W

Width:
0 HP :) - internal linear PSU solution for you modular system.

Outputs:
+12V / 1.5A
-12V / 1.5A
+5V / 0.7A

Output noise:
max 4.8mVpp on 100% load (20MHz BW)

Input:
230V AC (120V on request)

Dimensions:
27 × 8.6 × 5 cm

Weight:
2400g

Output Connectors:
2x 16 pin IDC for flat cable
WAGO spring terminals

Input connectors:
WAGO spring terminals
Panel with 5,5 x 2.1 DC input (center positive) and switch included

Protections:
Input filter
Output overvoltage
Output short circuit – automatic recovery
Output over current – automatic recovery
Thermal protection – automatic recovery
All output protections are independent for each rail

Other:
70µm cooper thickness on PCB
LEDs indicate present and drop of output voltage
Prewired IEC inlet with switch attached
