Dimensions
4 HP
25 mm deep
Current Draw
9 mA +12V
9 mA -12V
0 mA 5V
Price
$45 Price in €

Available as an assembled Module and as a DIY project.

This Module is currently available.

Multi Function Utility

4hp, 25mm Deep

2x Signal Inverters: Each one input and its Inverted output.

1x 3:1 Summing Mixer. 3 Input 1 Output DC coupled mixer for combining CV sources. Trim pot on back to calibrate accurate 1V/Oct Tracking.

1x Passive Switch. 2 Input ON-OFF-ON Switch with a single output shared on 2 jacks. Can be used in reverse, but will not sum inputs.

https://www.groundgrowncircuits.com/
https://github.com/GroundGrown


submitted Jun 11th 2021, 18:02 by groundgrown | last Change Apr 16th, 19:38 by groundgrown
