CLIP - unreleased prototype

Dual Halfwave & Fullwave Rectifier(s)

This is an unreleased prototype.

CLIP (name pending) has two circuits which rectify voltages above and below 0V.
The ABOVE output, clips all negative voltages and outputs positive in the 0 to 1V range.
The BELOW output clips all positive voltages and outputs the negatives in the 0 to 1V range.
The ABS, or Absolute, output folds the negative volatges up above 0V which has a frequency doubling effect on bipolar signals.
