12 HP
25 mm deep
Current Draw
? mA +12V
? mA -12V
? mA 5V

This Module is a prototype or in a concept phase.

Black Input module interfaces your modular system with other instruments. It features a pre-amp, versatile envelope follower and most importantly – an accurate, low latency pitch tracker that converts incoming audio into CV, so you can play your modular synth in unison with any external monophonic instrument, even a voice.

1. Balanced inputs with 6.3mm and 3.5mm
2. Input preamp with adjustable gain and level indicator
3. Envelope follower with adjustable threshold and rate
4. Gate and Trigger outputs
5. Accurate, low latency monophonic pitchtracker
6. Continuous and quantized (by semitones) CV outputs
7. Three pitchtracker modes
