Dimensions
16 HP
40 mm deep
Current Draw
100 mA +12V
50 mA -12V
0 mA 5V
Price
$120 Price in €

Module is available as a DIY project only.

This Module is a prototype or in a concept phase.

BMC 004 VC Clock/Divider (TBD 16HP Repanel)

This circuit generates a clock signal output and up to six additional outputs whose frequencies are divided by the master clock. There is an option for PWM on each of the divided clock outputs which sacrifices two of the outputs (4 divded outputs instead of 6). There are also options for random division and division of external clocks.
The board for this circuit has 4 CV mixers with over voltage protection which are not tied directly to any parameter, this gives the builder of the circuit options as to which parameters are voltage controlled.

http://www.bartonmusicalcircuits.com/vcclock/


submitted Jul 26th 2020, 22:26 by tbdsound
