Dimensions
4 HP
24 mm deep
Current Draw
? mA +12V
? mA -12V
? mA 5V
Price
$153 Price in €

This Module is currently available.

Row Power 40 - DUPLICATE

Unlisted Power

Power supply - DUPLICATE

Row Power is a clean, regulated, and protected power solution for eurorack systems.
A single Row Power module can power a small system, and multiple Row Powers can be daisy-chained to power a large system using a single power brick.
Simply plug a laptop-style universal power supply into the Row Power panel and connect your modules via Flying Bus cables or a Bus Stick.
You can even daisy-chain multiple Row Powers to use a single power brick for multiple rows. Each row will be independently regulated and protected for ultra-low cross-talk.

Two power jacks for daisy-chaining multiple Row Powers: a common laptop-style power brick typically powers 300-500HP.
On/off switch cuts power without interrupting the daisy-chain
Row Power 30 (white panel) provides more than enough power for 104HP of modules (sometimes up to two 84HP rows).
Row Power 40 (black panel) is suited for up to two eurorack rows (more than 200HP)
Ultra-clean: Each rail is separately regulated with high-grade circuitry
Runs cool: Row Power is efficient so it won't heat up itself or your system. Electronics like to chill!
Skiff-friendly: very shallow module fits in any case
CV/Gate headers for expansion
DIY-friendly: PCB pads for blade tabs for power entry, to be used in custom installations where the faceplate is not used
Row Power 30: +12V @ 1.5A, -12V @ 0.75A, +5V @ 0.5A
Row Power 40: +12V @ 1.5A, -12V @ 1.25A, +5V @ 1.5A
Power brick: 2.1mm barrel, positive center, 15V-20V.
4HP wide, 24mm deep (0.96"), up to 28mm (1.1") with power cable

http://www.4mspedals.com/rowpow.php
