Dimensions
26 HP
25 mm deep
Current Draw
350 mA +12V
0 mA -12V
0 mA 5V
Price
$599 Price in €

This Module is currently available.

Specs are approved by the manufacturer

24-bit sampler/looper

Say hello to bitbox. Bitbox delivers recording, clip launching, and looping in a musically intelligent way. With a 24-bit audio path, you can capture and play samples with impeccable audio quality. With clock and MIDI inputs, you can create loops pre-cut to bars or beats and launch clips with similar synchronization. Bitbox has a capacitive touch screen that makes easy work of tweaking, browsing, and loading sounds from microSD card.

Features:

Playback of up to 16 simultaneous samples from internal memory or up to 4 samples directly from microSD
Trigger samples with the touch screen, CV gate inputs, or MIDI input
Import or export WAV files with your Mac or PC using a microSD card
24-bit 48kHz stereo input and 4-channel output
Make recordings up to 4 hours in length
Various launch modes, including one-shot, toggle, gate, and repeat
Playback can be immediate or synchronized to analog or MIDI clock
Control of various sample parameters, including start position, length, pitch, gain, loop mode, and launch quantization
Stereo or mono recording with the option to synchronize the start and stop times to clock inputs
Save and recall up to 12 different banks of samples and their configuration
4 modulation inputs each capable of launching an entire row of clips at once or modulating sample start, length, or pitch
Export your sets to Ableton Live
Accepts TRS MIDI input compatible with Arturia and other products

http://1010music.com
