Kaoss Entrancer

controler video audio

The Kaoss Pad Entrancer builds on the success of the Kaoss Pad 2, offering the same versatile X-Y pad-driven audio processing capabilities, but adding video processing to give you real-time control over both sound and vision.

Effects: 100 video, 100 audio, 100 combination audio/video.

Inputs: Two (Input 1, on the rear of the KPE1, accepts a composite video signal via a phono connector, and stereo audio via left and right phono connectors, while Input 2, on the front edge of the KPE1, is video-only, accepting an S-Video signal via a mini-DIN socket or a composite video signal via a phono. Inputs 1 and 2 are switchable).

Main outputs: One (on the rear of the KPE1. An S-Video signal is available via mini-DIN, composite video is available on a phono, and individual Left and Right phonos handle the stereo audio output).

Headphone output: One (via quarter-inch stereo jack, on the front edge of the KPE1, with associated Volume control).

Sampling frequency: 44.1kHz.

A-D/D-A conversion: 20-bit linear.

MIDI connectors: In & Out.

Video format: Switchable between NTSC (the US standard) and PAL (the European standard).

Power supply: 7V DC (via external AC adaptor).
