hh110

clone of the boss dr110 hihat voice (micro-module)

The module is a clone of the hihat voice from the Boss DR-110. The sound generation and shaping follows the same method as the original (digital noise and summed square waves, with analogue envelope and VCA) — triggering both open and closed sounds simultaneously gives a third sonic permutation.

Controls

• oh decay changes the length of the open hihat sound.

Connectivity

As a drum voice, this one is hopefully self-explanatory!

Inputs

Each trigger is actually a pair of sockets acting as a local multiple.

• oh triggers the open hihat sound.
• ch triggers the closed hihat sound.

Triggering both open and closed sounds simultaneously gives an 'in-between' variation.

Outputs

• out the audio from the module.
