Master R5

Power, MIDI, Audio I/O, CV

The MASTER module is the base of an AE modular system if MIDI control has to be possible; it contains the voltage regulation (5V) for the power supply of the modules
a MIDI input (minijack; Breakout cable to DIN-5 socket is available separately); the MIDI channel can be selected between 1, 14, 15,16 or OMNI
In/out-sockets (3.5mm minijack) for audio out and/or interfacing with a Eurorack system
all bus signals (CV, GATE, CTRL, MIDI clock/start/stop) as patch sockets

The power supply is a 9V DC wall adapter (see here).

Note: The MASTER R5 is the latest revision of the MASTER module which is the core of most AE systems; what's new here is:

The bus signals CV, gate, ctrl CV, MIDI start/stop/clock can be connected with / removed from the bus individually with the microswitches
The TRS MIDI input now accepts both types of TRS-MIDI adapters
The mechanical design is changed to be compatible with the QUICKSWAP CASE. If you have to buy the MASTER R5 only because you are changing your AE system to a QUICKSWAP CASE, you get a 25% on this module, please contact us directly to get a coupon code.
