564 Sequential Divider Switch Sequencer Mod
- Dimensions
- 2 U
- 58 mm deep
- Current Draw
- 30 mA +15V
- 5 mA -15V
- 5 mA 5V
- Price
- $500
Module is available as a DIY project only.
This Module is a prototype or in a concept phase.
MG ID: 15151
JLR modification to turn the 564 into a CV sequencer
Removed the stage lamps
Added 100K pots where the lamps were
Added LEDs above the pots
Pots are wired between 0 volt and +5 volt rails
Pot wipers are connected to the switch lugs of the IN/OUT jacks
Ø 4.00 (1 Votes) Average Rating
submitted Jan 2nd 2018, 04:49 by JohnLRice
