Dimensions
5 HP
40 mm deep
Current Draw
40 mA +12V
10 mA -12V
0 mA 5V
Price
$102 Price in €

No info about availability.

Dual LFO with 8 waveforms

The ZONE B.F. ("Basse Frequence" = Low Frequencies) is a dual LFO module. Each LFO has 8 selectable waveforms, variable speed control and individual reset inputs.

This is the first silver version with 8 waveforms.

"Vitesse" = The speed of each LFO, ranging from 0.1 Hz to 390 Hz.

"Forme" = Wave shape: Either Triangle, ramp up, ramp down, square, random, digital noise, random squares (variable pulse length) , random triangles (variable amplitude & lengths)

"Sync 1 & 2" = Inputs to reset the respective LFO waveforms when a pulse signal is applied.

"Sortie" = LFO Outputs for LFOs 1 & 2

Dual LEDs indicate LFO activity.

http://www.eowave.com/shop/products.php?prod=1236


Ø 3.89 (9 Votes) Average Rating
submitted Sep 24th 2013, 23:02 by mylarmelodies | last Change Apr 19th 2020, 13:37 by deemsaar

18 Users are observing this
